Details
FRAME: Alloy 6061 w/Custom Formed TT & DT w/Replaceable Derailleur Hanger
FORK: Alloy Straight Leg w/CrMo Steerer
HEADSET: 1-1/8” Threaded, Zero Stack w/Alloy Conical Top Cap
RIMS: Alloy Double Wall, 26x32H
HUBS, FRONT: Alloy Disc w/CNC Rotor Flange, QR
HUBS, REAR: Alloy Disc w/CNC Rotor Flange, QR, Cassette
TIRES: Kenda Khan, 26x2.35 w/Anti-puncture
SPOKES: 14G Black, 32x32
DERAILLEUR, FRONT: Shimano FD-M310
DERAILLEUR, REAR: Shimano Altus RD-M310
SHIFTERS: Shimano SL-M315 Trigger
CHAIN: KMC Z8.3
CRANKSET: Shimano FC-TY301, 48/38/28 w/CG
BB: Cartridge Bearing
CASSETTE: Shimano CS-HG31-8,11-34T, 8 Speed
PEDALS: Wellgo Platform w/Non-slip Tread, DU Bearings
SEATPOST: Alloy Suspension, 27.2x350L
SADDLE: KHS Wide Comfort, Dual Density w/Elastomer Spring & Reflective Back
HANDLEBAR: Alloy 100mm rise/660mm
STEM: Alloy Quill, 25 Degree, S:80mm, M-L:100mm
GRIP: Comfort Kraton
BRAKE LEVERS: Alloy Linear Pull
BRAKES: Radius Cable Disc BR-CX7, 160mm Rotors w/ABS System
Specs
Frame | 6061 Aluminum w/Custom Formed T/T & D/T w/Replaceable Derailleur Hanger, Internal Cable Routing |
---|---|
Fork | Aluminum Straight Leg w/CrMo Steerer |
Headset | 1-1/8” Threadless, Zero Stack w/Aluminum Conical Top Cap |
Rims/Wheels | Alex EV-23 Aluminum Double Wall, 26x32H |
Hubs | Aluminum Disc w/CNC Rotor Flange, QR, Cassette |
Spokes | 14G Stainless Black, 32x32 |
Tires | Kenda Khan, 26 x 2.35” w/Anti-Puncture |
Crankset | Shimano FC-TY301, 48/38/28T w/Chainguard, 170mm |
Chainwheel | Shimano, CS-HG31-8,11-34T, 8-Speed |
Chain | KMC Z8.3 |
Front Derailleur | Shimano Altus, FD-M310, 31.8mm |
Rear Derailleur | Shimano Altus, FD-M310, 31.8mm |
Shifters | Shimano, SL-M315 Trigger |
Handlebars | Aluminum, 100mm rise, 660mm |
Tape/Grips | Comfort Kraton |
Stem | Aluminum Threadless, 17 Degree |
Brakes | Aluminum Linear Pull |
Pedals | Wellgo Platform w/Non-slip Tread, DU Bearings |
Saddle | DDK Wide Comfort, Memory Foam w/Elastomer Spring |
Seat Post | Aluminum Suspension, 27.2mm |
* Subject to change without notice.
Part Numbers
Option | MPN | Store SKU |
---|---|---|
Red / Small | ||
Red / Medium | 42-0355 | 210000076589 |
Red / Large | 42-0360 | 210000076588 |
