KHS Flite 150
Details
FRAME: New Disc Design, Alloy 6061 w/Custom Formed Double Butted T/T & D/T, Internal Cable, Flat Mount Disc, Replaceable Derailleur Hanger
FORK: Hi-Tensile Unicrown, Straight Blades
HEADSET: Threadless 1-1/8”
RIMS: Alloy Double Wall w/CNC Sidewall
HUBS, FRONT: Alloy QR
HUBS, REAR: Alloy QR, Cassette
TIRES: Kenda K-176 Road, 700x28C
SPOKES: 14G Black, 28x32
DERAILLEUR, FRONT: Shimano FD-A070, 31.8
DERAILLEUR, REAR: Shimano RD-A070
SHIFTERS: Shimano STI, ST-A070
CHAIN: KMC Z8.3
CRANKSET: Prowheel Solid, Forged, 3-pc, 50-34T, XS-XL:170, Ladies:165
BB: Cartridge Bearing
CASSETTE: Shimano Csst, HG20-7, 12-28T, 7 Speed
PEDALS: Wellgo Resin w/Alloy Cage & DU Bearing
SEATPOST: Alloy Micro-adjust, 27.2x350mm
SADDLE: KHS Road Padded
HANDLEBAR: Alloy Drop, Compact Bend, 31.8, XS-ML:42cm, L-XL:44cm, Ladies:38cm
STEM: Alloy 3D Forged, Threadless 4-bolt, 7-degree, 31.8, XS-S:90mm, M-ML:100mm, L-XL:110mm, Ladies:80mm
GRIP: Cushion Tape
BRAKE LEVERS: Shimano STI, ST-A070
BRAKES: Tektro MD-C310, Flat Mount Road Mechanical Disc Brake w/160mm Rotors
Specs
| Frame | New Disc Design, Alloy 6061 w/Custom Formed Double Butted T/T & D/T, Internal Cable, Flat Mount Disc, Replaceable Derailleur Hanger |
|---|---|
| Fork | Hi-Tensile Unicrown, Straight Blades |
| Headset | Threadless 1-1/8” |
| Rims/Wheels | Alloy Double Wall w/CNC Sidewall |
| Hubs | Alloy QR, Cassette |
| Spokes | 14G Black, 28x32 |
| Tires | Kenda K-176 Road, 700x28C |
| Crankset | Prowheel Solid, Forged, 3-pc, 50-34T, XS-XL:170, Ladies:165 |
| Chainwheel | Shimano Csst, HG20-7, 12-28T, 7 Speed |
| Bottom Bracket | Cartridge Bearing |
| Chain | KMC Z8.3 |
| Front Derailleur | Shimano FD-A070, 31.8 |
| Rear Derailleur | Shimano RD-A070 |
| Shifters | Shimano STI, ST-A070 |
| Handlebars | Alloy Drop, Compact Bend, 31.8, XS-ML:42cm, L-XL:44cm, Ladies:38cm |
| Tape/Grips | Cushion Tape |
| Stem | Alloy 3D Forged, Threadless 4-bolt, 7-degree, 31.8, XS-S:90mm, M-ML:100mm, L-XL:110mm, Ladies:80mm |
| Brake Levers | Shimano STI, ST-A070 |
| Brakes | Tektro MD-C310, Flat Mount Road Mechanical Disc Brake w/160mm Rotors |
| Pedals | Wellgo Resin w/Alloy Cage & DU Bearing |
| Saddle | KHS Road Padded |
| Seat Post | Alloy Micro-adjust, 27.2x350mm |
* Subject to change without notice.
Part Numbers
| Option | MPN | Store SKU |
|---|---|---|
| Gray / XS/49 | ||
| Gray / S/52 | ||
| Gray / M/55 | ||
| Gray / L/58 | 42-1665 | 210000076597 |
| Gray / XL/61 |
