Details
Frame
TIG-Welded Hi-Tensile Steel, Internal Cables
Rear Shock
n/a
Fork
Hi-Tensile Unicrown Straight Blades
Headset
1-1/8” Threaded, Zero Stack w/Aluminum Conical Top Cap
Rims
Aluminum, 700c, 32H
Hubs, Front
Aluminum, QR, Rubber Seal
Hubs, Rear
Aluminum, QR, Rubber Seal
Tires
Kenda Khan, 700 x 38c, Skin Wall w/Anti-Puncture
Spokes
14G Stainless, 32x32
Derailleur, Front
Shimano Tourney, TY510, 28.6mm
Derailleur, Rear
Shimano Tourney, RD-TY300D
Shifters
Shimano Revo RS36
Chain
KMC Z8.3
Crankset
Shimano FC-TY501, 48/38/28T w/CG, S-M:170, L-XXXL:175
BB
Cartridge Bearing
Freewheel
Shimano Mega Range, 14-34T, 7-Speed
Pedals
Nylon Platform
Seatpost
Aluminum Suspension, 25.4mm
Saddle
DDK Wide Comfort, Memory Foam w/Elastomer Spring
Handlebar
Aluminum, 100mm rise, 660mm
Stem
Aluminum Quill, 25 Degree
Grips
Comfort Kraton
Brake Levers
Aluminum Linear Pull
Brakes
Aluminum Linear Pull w/ABS System
Click for more information about BrakeSafe
Color
Audi Gray, Black, Matte Green; Low-Step: Black, Coral, Stone Green
Frame Size
S/15, M/17, L/19, XL/21, XXL/23, XXXL/25 (XXL/23 & XXXL/25 Black Only); Ladies: S/14L & M/17L Low-Step
Specs
Frame | TIG-Welded Hi-Tensile Steel, Internal Cables |
---|---|
Fork | Hi-Tensile Unicrown Straight Blades |
Headset | 1-1/8” Threaded, Zero Stack w/Aluminum Conical Top Cap |
Rims/Wheels | Aluminum, 700c, 32H |
Hubs | Aluminum, QR, Rubber Seal |
Spokes | 14G Stainless, 32x32 |
Tires | Kenda Khan, 700 x 38c, Skin Wall w/Anti-Puncture |
Crankset | Shimano FC-TY501, 48/38/28T w/CG, S-M:170, L-XXXL:175 |
Chainwheel | Shimano Mega Range, 14-34T, 7-Speed |
Bottom Bracket | Cartridge Bearing |
Chain | KMC Z8.3 |
Front Derailleur | Shimano Tourney, TY510, 28.6mm |
Rear Derailleur | Shimano Tourney, RD-TY300D |
Shifters | Shimano Revo RS36 |
Handlebars | Aluminum, 100mm rise, 660mm |
Tape/Grips | Comfort Kraton |
Stem | Aluminum Quill, 25 Degree |
Brake Levers | Aluminum Linear Pull |
Brakes | Aluminum Linear Pull w/ABS System |
Pedals | Nylon Platform |
Saddle | DDK Wide Comfort, Memory Foam w/Elastomer Spring |
Seat Post | Aluminum Suspension, 25.4mm |
* Subject to change without notice.
Part Numbers
Option | MPN | Store SKU |
---|---|---|
Green / Small | 42-0225 | 210000076584 |
Green / Medium | 42-0230 | 210000076583 |
Coral / Small | 42-0232 | 210000076595 |
Coral / Medium | ||
Black / Small | ||
Black / Medium | 42-0220 | 210000076594 |
